UB-UVC-AI-LPR
Ubiquiti UniFi Protect 8MP LPR camera with 4.1mm - 12.3mm Lens
Overview:
UVC-AI-LPR-BSpecialized 4K camera with 3x optical zoom and long-range IR night vision optimized for recognizing license plates on vehicles moving up to 90 km/h.
Note . The AI-LPR is optimized to exclusively capture reflective or non-reflective license plates at night. Install additional cameras to capture other vehicle details in dark conditions
Specifications:
| © 2025 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered. | |
Specifications![]() | |
| Product Code | UB-UVC-AI-LPR![]() |
| Overview | |
| Dimensions | 130 x 151.4 x 302.9 mm |
| (5.1 x 6 x 11.9") | |
| IR Night Vision | 15 m (50 ft) |
| Zoom Mode | 3x Optical |
| License Plate Recognition | Yes |
| Smart Detections (People, Vehicles, Animals) | Yes |
| Resolution | 4K |
| Field of View | Wide: H 109.9°, V 60°, D 127.7° |
| Tele: H 35°, V 19.8°, D 40° | |
| Audio | Microphone |
| Weatherproofing | IP66 |
| Tamper Resistance | IK04 |
| Mounting | Wall, ceiling, pole mount (Included) |
| Junction box, angled base (Optional) | |
| Performance | |
| Networking Interface | GbE RJ45 port |
| Video | |
| Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay |
| Max. Frame Rate | 30 FPS |
| Resolution | 8MP 3840 x 2160 (16:9) |
| Optics | |
| Sensor | 1/1.8" 8MP |
| Lens | F 4.1-12.3 mm , ƒ/1.53-ƒ/3.3 |
| IR Capture Distance | 15 m (50 ft) |
| LPR Night Mode | LPR optimization filter |
| Hardware | |
| Max. Power Consumption | 25.5W |
| Supported Voltage Range | 42.5-57V DC |
| Power Method | PoE+ |
| Processor | Quad-core Arm Cortex -A53 based chip |
| Pole Mount Diameter | 1.5-2" (38-50 mm) |
| Weight | 1.5 kg (3.3 lb) |
| Enclosure Material | Aluminum alloy, polycarbonate |
| Mount Material | Aluminum Alloy |
| Expansion Slot | Micro SD memory card |
| Button | (1) Factory-reset |
| Cable | |
| Cable Connector Type | RJ45 |
| Cable Diameter | 4.5 mm (0.2") |
| Cable Length | 30 cm (1 ft) |
| Jacket Material | Thermoplastic elastomer |
| Jacket Enclosure Dimensions | Ø20 x 70.6 mm (0.8 x 2.8") |
| Jacket Enclosure Material | Thermoplastic elastomer, polycarbonate, silicone rubber |
| Ambient Operating Temperature | -20 to 50° C (-4 to 122° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
