TP-VIGI-C540S-4

TP-Link Vigi C540S Vigi 4MP Outdoor ColorPro Night Vision Pan Tilt Network camera with 4mm Lens

TP-Link Vigi C540S Vigi 4MP Outdoor ColorPro Night Vision Pan Tilt Network camera with 4mm Lens, Pan / Tilt, 2 White LED with 30m range, No IR LED, 2688x1520 maximum Resolution, Image enhancement - BLC / 3D DNR / HLC, 120dB wide Dynamic range, 1 region ROI, Two-Way audio, ONVIF, 3 main streams & 3 Sub-Streams, Motion Detection, Video tampering detection, Exception (Illegal Login), 1x RJ45 10/100 Mbit Self-Adaptive Ethernet Port PoE Network Interface, Built-In Memory card slot, Support MicroSD card up to 512 GB, Built-In Microphone, Built-In Speaker, IP66 protection

Overview:

VIGI C540S 4MP Outdoor ColorPro Night Vision Pan Tilt Camera
TP-Link's VIGI C540S is a 4MP outdoor Pan Tilt network camera designed to deliver high-quality color video in all lighting conditions. With advanced night vision, AI-powered analytics, and robust outdoor protection, this camera ensures comprehensive monitoring for your property or business.

Description:

The VIGI C540S offers ultra-low light color night vision, full 360degrees monitoring, and smart human and vehicle detection. Equipped with two-way audio, face recognition, and automatic tracking, it provides real-time alerts and enhanced security. H.265+ compression optimizes storage and bandwidth, while IP66 weatherproofing ensures reliable performance outdoors. Local microSD storage up to 512 GB makes it easy to retain footage without relying on cloud services.

Features:

Exceptional Night Vision for 24/7 Security
VIGI's ColorPro Night Vision technology captures crisp, full-color video even in extreme low-light conditions. Unlike traditional cameras, it maintains image clarity and vibrant colors without additional lighting, reducing environmental light pollution while providing actionable visuals.

• Ultra-low light color imaging
• 4MP high resolution for sharp detail
• True wide dynamic range for balanced images
• Minimal digital noise in dark environments

Advanced Pan Tilt Monitoring
The camera supports flexible Pan Tilt operation, allowing you to cover every corner without blind spots. Customizable patrol routes and preset angles reduce manual monitoring while keeping key areas under constant surveillance.

• 360degrees horizontal rotation
• 300 preset positions
• 8 patrol routes with adjustable speed
• Quick pan and tilt control up to 44degrees/s

Smart Human and Vehicle Detection
VIGI's AI-powered algorithms accurately identify humans and vehicles, differentiating them from other moving objects. This ensures more relevant alerts and efficient monitoring.

• Automatic tracking of persons or vehicles
• Customizable alarm rules for enhanced accuracy
• Instant notifications for unusual activity

Comprehensive AI-Based Alerts
The camera can detect a range of abnormal events based on pre-set rules. This reduces false alarms while covering various security needs.

• Intrusion detection
• Line-crossing detection
• Region entering and exiting detection
• Abandoned object detection
• Object removal detection
• Loitering detection

Face Recognition and Analytics
The built-in face recognition system captures facial features and matches them against a library to identify individuals quickly. Combined with advanced people and vehicle analytics, it helps you find relevant activity in seconds.

• Identify people by clothing, hair, and other attributes
• Search for vehicles by type and color
• Enhance access control and attendance management

Active Defense and Two-Way Communication
The camera can alert intruders using sound and light, providing immediate deterrence. Two-way audio lets you communicate remotely with anyone on the premises.

• Real-time audio intercom
• Remote interaction from anywhere
• Instant visual and audio alerts

Efficient Storage and Video Compression
With H.265+ smart video coding, the camera compresses video without losing quality, saving disk space and reducing network load. Local storage is available with a microSD card slot supporting up to 512 GB.

• PoE network connection simplifies installation
• IP66 weatherproof design for stable outdoor use
• Flexible storage options for long-term retention

Remote Control and Custom Monitoring
The VIGI app and client allow you to manage cameras from anywhere. Set motion zones, adjust rotation angles, control patrols, and zoom in or out to meet specific security needs.

Reliable Protection for Your Business
TP-Link's VIGI professional surveillance system is designed to protect your property and business efficiently. With high-quality construction, AI intelligence, and simplified setup, it ensures reliable monitoring at all times.

Specifications:

© 2025 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	TP-VIGI-C540S-4
CAMERA
Image Sensor	1/1.79" Progressive Scan CMOS
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	0.0005 Lux, 0 Lux with White Light
Day/Night Mechanism	N/A
Day/Night Switch	Unified/Scheduled/Auto
LENS
Type	Fixed Focal Lens
Focal Length	4 mm
Aperture	F1.0±5%
FOV	4mm:
	Horizontal FOV: 104degrees, Vertical FOV: 55degrees, Diagonal FOV: 127degrees
Lens Mount	M16*P 0.5
DORI Distance	4 mm:
	Detect: 63 m (207 ft)
	Observe: 26 m (86 ft)
	Recognize: 13m (41 ft)
	Identify: 6 m (21 ft)
PTZ
Pan/tilt Range	Pan: 0degrees to 348degrees, Tilt: 0degrees to 105degrees
Pan/tilt Speed	Pan Speed:
	Configurable from 8degrees to 44degrees/s, Preset Speed: 44degrees/s
	Tilt Speed:
	Configurable from 8degrees to 44degrees/s, Preset Speed: 44degrees/s
Manual Control Speed	Configurable from 8degrees to 35degrees/s
Presets	300
Patrol Scan	8 patrols, up to 8 presets for each patrol
Power-off Memory	Yes
	Auto restore to previous PT and lens status after power failure
Park Action	Yes
	Preset, Patrol Scan
3D Positioning	Yes
ANGLE ADJUSTMENT (MANUAL)
Range	Pan: 0degrees to 348degrees
	Tilt: 0degrees to 105degrees
ILLUMINATOR
IR LED	N/A
White LED	Quantity: 2
	Range: 30m
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution	2688 x 1520
Main Stream	Frame Rate:
	50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
	60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution:
	2688x1520, 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
Sub-Stream	Frame Rate:
	50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
	60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution:
	704x576, 640x480, 352x288, 320x240
Bit Rate Control	CBR, VBR
Video Compression	Main Stream: H.265+/H.265/H.264+/H.264
	Sub-Stream: H.265/H.264
H.264 Type	Main Profile/High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Video Bit Rate	Main Stream: 256 Kbps to 6 Mbps
	Sub-Stream: 64 Kbps to 512 Kbps
Image Settings	Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR
	White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image Enhancement	BLC/3D DNR/HLC
Wide Dynamic Range	120dB
	Note: When Face Recognition s is enabled, only DWDR is supported.
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
AUDIO
Audio Communication	Two-Way Audio
Audio Input	Yes
Audio Output	Yes
Audio Compression	Yes
Audio Sampling Rate	8KHz
Environment Noise Filtering	Yes
Audio Bit Rate	64 Kbps(G.711 alaw)
NETWORK
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF	Yes
API	ONVIF
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Client	VIGI App, VIGI Security Manager, Web UI
Web Browser	Google Chrome 57 and above
	Firefox 52 and above
	Safari 11 and above
	Microsoft Edge 91 and above
Cloud	Yes
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
ALARM AND EVENT MANAGEMENT
Smart Event	Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection, Loitering Detection, Scene Change Detection, Smart Frame
Basic Event	Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm Linkage	Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage Method	N/A
Output Notification	Message Push
DEEP LEARNING FUNCTION
People & Vehicle Analytics	Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
Face Capture	Support
Face Comparison	Support
INTERFACES
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm	N/A
Reset Button	Yes
Power	DC Power Port
On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB
Built-in Microphone	Yes, Records Anything Going on within a 15-ft Radius of the Camera
Built-in Speaker	Yes
Audio	N/A
GENERAL
Operating Temperature	-30-60 degreesC
Storage Temperature	-40-60 degreesC
Operating Humidity	95% or Less (Non-Condensing)
Storage Humidity	95% or Less (Non-Condensing)
Package Contents	VIGI Network Camera
	Quick Start Guide
	Waterproof Cable Attachments
	Mounting Accessories
Material	Plastic
Power Supply	12V DC ± 5%, Max. 13.13 W, 5.5mm Coaxial Power Plug
	PoE: 802.3at, class 4, Max. 16.47 W
Protection	IP66
Product Dimensions (L x W x H)	120 x 172 x 203 mm
Certifications	CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
