TP-VIGI-C230I-MINI-28

TP-Link C230I Mini Vigi 3MP IR Mini Dome Network Camera with 2.8mm lens

TP-Link C230I Mini Vigi 3MP IR Mini Dome Network camera with 2.8mm Lens, 3D DNR, DWDR, 2304x1296 maximum Resolution, H.265+ / H.265 / H.264+ / H.264 Video Compression, 2 IR LED 30m range, BLC / 3D DNR / HLC / SmartIR, 1 region ROI, Two-Way audio, ONVIF, 1x RJ45 10/100 Mbit Self-Adaptive Ethernet Port, DC Power Port, Support MicroSD card up to 256 GB, Built-In Microphone, Built-In Speaker

Overview:

VIGI C230I Mini - 3MP IR Mini Dome Network Camera
The VIGI C230I Mini is a compact, high-performance dome network camera designed for professional security monitoring. Combining super-high 3MP resolution, AI-powered smart detection, and advanced video processing technologies, it delivers reliable surveillance for small spaces like corridors, elevators, and convenience stores. Its vandal-proof design ensures durability, while smart features and flexible storage options make security management simple and efficient.

Description:

This 3MP IR Mini Dome Camera offers crystal-clear video with human and vehicle classification, two-way audio, and smart detection alerts. The ultra-wide 2.8 mm lens captures expansive areas, while smart video enhancements like WDR, Smart IR, and Night Vision improve image quality. The camera supports onboard storage up to 256 GB, ONVIF compatibility for network flexibility, and corridor mode for narrow spaces. Ideal for small businesses, ATMs, and high-traffic indoor areas, it combines compact design with professional-grade security.

Features:

High-Definition Surveillance
Equipped with a 3MP sensor, the VIGI C230I Mini captures detailed footage with clarity that ensures no critical details are missed. The high-resolution output allows for precise monitoring of all activities within the camera's field of view.

AI-Powered Human and Vehicle Classification
Advanced AI algorithms differentiate between humans, vehicles, and other objects. This reduces false alarms and ensures that notifications are accurate. Customizable alarm rules let you tailor alerts to your specific monitoring needs.

Smart Detection for Real-Time Alerts
Receive instant notifications for a variety of events:

• Motion Detection
• Intrusion Detection
• Line-Crossing
• Object Removal
• Object Abandonment
• Camera Tampering

Compact Design with Wide-Angle Coverage
The 2.8 mm ultra-wide-angle lens allows the camera to cover larger areas despite its small form factor. Perfect for corridors, elevators, small warehouses, and convenience stores where space is limited but monitoring requirements are high.

Two-Way Audio for Interactive Security
Built-in microphone and speaker enable direct communication, allowing you to respond to incidents in real time or issue warnings remotely.

Vandal-Proof for Reliable Protection
With an IK08-rated dome casing, the camera withstands tampering and physical damage, making it suitable for high-risk locations like ATMs, checkout counters, and public corridors.

Efficient Video Compression
H.265+ compression ensures high-quality video while reducing bandwidth usage and storage needs. This minimizes network load and lowers monitoring costs without sacrificing image clarity.

Smart Video Enhancement
Technologies such as Smart IR, WDR, 3D DNR, and Night Vision enhance video quality in low-light conditions and challenging environments, ensuring all recorded footage is clear and actionable.

Corridor Mode for Narrow Spaces
Rotate the camera image 90degrees to change the aspect ratio from 16:9 to 9:16 . This is ideal for monitoring long, narrow areas like hallways and aisles, providing a natural viewing perspective.

ONVIF Compatibility for Network Flexibility
The camera supports ONVIF standards, allowing integration with other VIGI cameras or third-party devices. This makes it easy to build a scalable and diverse security network.

Flexible Management and Storage Options
Control and manage your camera via multiple platforms: web UI, NVR UI, VIGI app, or VIGI Security Manager. Local storage is supported through SD cards up to 256 GB, and all management methods allow full access to live feeds, recordings, and alerts.

Specifications:

© 2025 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	TP-VIGI-C230I-MINI-28
CAMERA
Image Sensor	1/2.8" Progressive Scan CMOS
Shutter Speed	1/3 to 1/10000 s
Slow Shutter	Yes
Minimum Illumination	Color: 0.1 Lux, 0 Lux with IR
Day/Night Mechanism	IR Cut Filter
Day/Night Switch	Unified/ Scheduled/ Auto
Lens	2.8 mm
Aperture	F1.6
Lens Mount	M12
Viewing Angle	Horizontal FOV: 106.9degrees, Vertical FOV:56.9degrees, Diagonal FOV: 127.9degrees
IR Working Distance	30m
Digital Noise Reduction	3D DNR
WDR	DWDR
LENS
Type	Fixed Focal Lens
Focal Length	2.8 mm
Aperture	F1.6
FOV	2.8mm: Horizontal FOV: 106.9degrees, Vertical FOV:56.9degrees, Diagonal FOV: 127.9degrees
Lens Mount	M12
DORI Distance	2.8mm
	Detect: 49 m (161 ft)
	Observe: 20 m (67 ft)
	Recognize: 10 m (32 ft)
	Identify: 5 m (16 ft)
VIDEO
Max. Resolution	2304 x 1296
Main Stream	Frame Rate :
	50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
	60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720
	Note: If the image rotation is set to 90degrees or 270degrees, the frame rate only supports up to 20fps.
Sub-Stream	Frame Rate :
	50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
	60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution: 704x576, 640x480, 352x288, 320x240
	Note: If the image rotation is set to 90degrees or 270degrees, the frame rate only supports up to 20fps.
Bit Rate Control	CBR, VBR
Video Compression	Main Stream: H.265+/H.265/H.264+/H.264
	Sub-Stream: H.265/H.264
H.264 Type	Main Profile/High Profile
H.264+	Main Stream Supported
H.265 Type	Main Profile
H.265+	Main Stream Supported
Video Bit Rate	Main Stream: 256 Kbps to 4 Mbps
	Sub-Stream: 64 Kbps to 512 Kbps
ILLUMINATOR
IR LED	Quantity: 2
	Range: 30m
	Wavelength: 850nm
White LED	N/A
Illuminator On/Off Control	Auto/Scheduled/Always on/Always off
ANGLE ADJUSTMENT (MANUAL)
Range	Pan: -30degrees to 30degrees
	Tilt: 0degrees to 85degrees
	Rotate: -15degrees to 15degrees
Image Settings	Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, HLC Adjustable by Client Software, Rotation (90degrees/270degrees)
Image Enhancement	BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range	DWDR
SNR	≥ 52 dB
Image Parameters Switch	Yes
Privacy Mask	Up to 4 Masks
ROI	1 Region
OSD Setting	Yes
AUDIO
Audio Communication	Two-Way Audio
Audio Input	Yes
Audio Output	Yes
Audio Compression	Yes
Audio Sampling Rate	8KHz
Environment Noise Filtering	Yes
Audio Bit Rate	64 Kbps(G.711 alaw)
NETWORK
Security	Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Protocol	TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS
	RTSP, NTP, UPnP UDP, SSL/TLS
API	ONVIF
Simultaneous Live View	3 Main Streams & 3 Sub-Streams
Client	VIGI App, VIGI Security Manager, VIGI NVR, Web
Web Browser	Open Network Video Interface (Profile S)
Cloud	Yes
ONVIF	Yes
INTERFACES
Network Interface	1 RJ45 10/100M Self-Adaptive Ethernet Port
Alarm	N/A
Reset Button	Yes
Power	DC Power Port
Button	Reset Button
Video Output	-
On-board Storage	Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
Built-in Microphone	Yes
Built-in Speaker	Yes
Audio	N/A
ALARM AND EVENT MANAGEMENT
Smart Event	Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection
Basic Event	Motion Detection, Video Tampering Detection, Exception ( Illegal Login)
Alarm Linkage	Memory Card Video Recording, Message Push, Audible Warning
Linkage Method	N/A
Output Notification	Message Push
GENERAL
Package Contents	VIGI Network Camera
	Quick Start Guide
	Mounting Accessories
	Mounting Template
Operating Temperature	-30-60 degreesC
Storage Temperature	-40-60 degreesC
Storage Humidity	95% or Less (Non-Condensing)
Operating Humidity	95% or Less (Non-Condensing)
Dimensions( H X W X D )	114 x 114 x 58 mm
Material	Plastic
General Features	Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Net Weight	0.23 kg
Gross Weight	0.41 kg
Power Consumption	12V DC: Max 7.5W
	PoE: Class 0
Power Supply	12V DC ± 5%, 5.5mm Coaxial Power Plug
	PoE (802.3af/at, class 0)
Vandal Resistant	IK08
Protection	IK08
Product Dimensions (L x W x H)	114 x 58 x 114 mm
Certifications	CE/VCCI/BSMI/KC/ONVIF
VIDEO/IMAGE
Video Compression	Main Stream: H.265+/H.265/H.264+/H.264
	Sub-Stream: H.265/H.264
Frame Rate & Resolutions	Main Stream:
	Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution: 2304x1296, 2048x1280, 1920x1080, 1280x720
	Sub-Stream:
	Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
	Resolution: 704x576, 640x480, 352x288, 320x240
Max. Resolution	3MP (2304 x 1296)
Video Streaming	3 Main Streams
	3 Sub-Streams
Image Settings	Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software, Rotation(90degrees/270degrees)
Image Enhancement	BLC/3D DNR/HLC/SmartIR
Video Bit Rate	64 Kbps to 4 Mbps
Day/Night Switch	Day/Night/Auto/Schedule
SMART FEATURE-SET
Smart Event	Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection
Basic Event	Motion Detection, Camera Tampering Detection, Exception (Illegal Login)
Linkage Method	Trigger Notification: ONVIF, HTTPS
Region of Interest	1 Region
