523301

Intellinet 5-Port Fast Ethernet Office Switch Metal case

Overview:

Easily add more computers or other Ethernet devices to your network
The INTELLINET NETWORK SOLUTIONS 5-Port Fast Ethernet Office Switch is perfect for the small and medium-size business looking a durable switch that is reliable and easy to install. The metal case is more durable than a plastic enclosure, and is very appropriate for locations with potentially harsh environments, such as a warehouse, factory or wiring closet.

Green Ethernet Technology
More often than not, a network switch does not utilize all its ports at all times. Normally, when a computer, notebook, network printer or other network device is powered down, the switch continues to consume the same amount of power as if it were active. Now, thanks to the new energy efficient IEEE 802.3az technology, the Intellinet 10/100 Mbps switch detects link status to all connected devices and reduces the power usage of ports not in use. In addition, the Intellinet switch can adjust the level of power output based on the length of the network cable connected to a particular port. With the Intellinet Network Solutions Fast Ethernet Office Switch you will enjoy maximum network performance, but when things slow down it automatically scales back power usage to conserving energy and save money.

Versatile
The Fast Ethernet Office Switch connects up to five computers, servers, printers, switches or any other Ethernet devices at 10 or 100 Mbps over Ethernet cables, and works with any operating system.

Easy to Install and Maintain
The auto features of this switch make installation Plug and Play and hassle free. There is no configuration required, and you don’t need to worry about using special cables for uplink ports, since each port is equipped with Auto MDI/MDI-X crossover.

Features:

Five 10/100 auto-sensing ports - automatically detect optimal network speeds
Supports any combination of 10 Mbps or 100 Mbps network devices
Green Ethernet power-saving technology deactivates unused ports and adjusts power levels based on the cable length
All RJ-45 ports with Auto-MDIX (auto uplink) support
Supports NWAY auto-negotiation
Store and forward switching architecture
Full/half duplex operation
IEEE 802.3x flow control for full duplex
Zero packet loss back-pressure flow control for half duplex
Packet filtering/forwarding rates: 148.800 pps (100 Mbps), 14.880 pps (10 Mbps)
Supports 1024 MAC address entries
48 kBytes buffer memory
LEDs for power, link/activity, full/half duplex
Compact metal case

Specifications:

© 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications for the product series
Product Code	523301
Standards	IEEE 802.3 (10Base-T Ethernet)
	IEEE 802.3u (100Base-TX Fast Ethernet)
	IEEE 802.3x (flow control, for full duplex mode)
	IEEE 802.3az (Energy Efficient Ethernet)
General	Media support:
	- 10Base-T Cat3, 4, 5 UTP/STP RJ-45
	- 100Base-TX Cat5 UTP/STP RJ-45
	Packet filter/forwarding rate:
	- 148.800 pps (100 Mbps)
	- 14.880 pps (10 Mbps)
	Buffer memory: 48 kBytes
	MAC address table: 1024 entries
	Switch architecture: store and forward
	Certifications: FCC Class B, CE Mark
LEDs	Power
	Link/TX
	Full/half duplex
Power	External power adapter: 5 V, 600 mA
Environmental	Metal housing
	Dimensions: 75 (L) x 121 (W) x 25 (H) mm (2.9 (L) x 4.7 (W) x 1.0 (H) in.)
	Weight: 420 g (0.9 lbs.)
	Operating temperature: 0° to 55°C (32° to 140°F)
	Operating humidity: 10% to 90% RH, non-condensing
	Storage temperature: -20° to 90°C (-4° to 194°F)
Package contents	5-Port Fast Ethernet Office Switch
	External power adapter
	User manual
