HK-311324227

Hikvision 4MP Smart Hybrid Light with ColorVU Fixed Bullet Network camera with 2.8mm lens

Hikvision 4MP Smart Hybrid Light with ColorVU Fixed Bullet Network camera with 2.8mm Lens, 2688x1520 maximum Resolution, IR & White Light supplement Light Type up to 60 m, H.265 / H.264 / H.264+ / H.265+ Video Compression, 1 fixed region interest (ROI), Mono sound audio Type, Up to 6 channels simultaneous live View, BLC, HLC, 3D DNR, Defog, 130 dB wide Dynamic range (WDR), 1x RJ45 10M/100M Self-Adaptive Ethernet Port, Built-In Memory card slot up to 512 GB, Built-In Microphone, Built-In Speaker, 1 Input line in audio, 1 Input line out audio, 1 Input & 1 Output alarm, Motion Detection, Human and vehicle, Face capture, DS-2CD2T47G2H-LISU/SL(2.8mm)(eF)(O-STD)

Overview:

Hikvision DS-2CD2T47G2H-LISU/SL 4MP ColorVu Smart Hybrid Light Bullet Network Camera
Hikvision DS-2CD2T47G2H-LISU/SL
4 MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera

• High quality imaging with 4 MP resolution
• Smart Hybrid Light: advanced technology with long range
• Clear imaging against strong back light due to 130 dB WDR technology
• Efficient H.265+ compression technology
• Focus on human and vehicle classification based on deep learning
• Active strobe light and audio alarm to warn intruders off
• Provide real-time security via built-in two-way audio
• Support on-board storage up to 512 GB with SD card slot
• Audio and alarm interface available
• Water and dust resistant with IP67 protection

Description:

The Hikvision DS-2CD2T47G2H-LISU/SL is a 4MP ColorVu fixed bullet network camera designed for reliable security monitoring in both day and night conditions. Its Smart Hybrid Light system combines infrared and white light illumination, providing up to 60 metres of supplemental lighting while allowing the camera to deliver clear images in changing lighting conditions.

With 2688 x 1520 resolution and ColorVu imaging technology, this Hikvision 4MP security camera is suited to applications where image detail and dependable low-light performance are important. The camera also uses 130 dB WDR to help maintain image clarity when strong backlighting or high-contrast scenes are present.

Intelligent detection is another key part of the camera. Deep learning technology enables human and vehicle classification, helping to reduce unwanted detection events compared with basic motion detection. Face capture is also supported, while active strobe lighting and audio alarms can provide a visible and audible deterrent when suspicious activity is detected.

The built-in microphone and speaker support two-way audio, making it possible to communicate with people near the camera. For recording flexibility, the integrated memory card slot supports up to 512 GB of storage. The camera also includes alarm and audio interfaces for integration with compatible security equipment.

Features:

Hikvision 4MP Camera Image Quality
The 4MP image sensor provides a maximum resolution of 2688 x 1520, delivering detailed footage for general surveillance, entrances, driveways, commercial properties and other monitored areas. BLC, HLC, 3D DNR, defog and 130 dB WDR technologies help the camera maintain usable images across a wide range of lighting conditions.

The 130 dB WDR capability is particularly useful for entrances and areas exposed to strong sunlight, headlights or other bright backgrounds.

Smart Hybrid Light and ColorVu Night Vision
Smart Hybrid Light combines infrared and white light illumination to provide flexible night-time monitoring. The supplemental light system reaches up to 60 metres, helping extend useful visibility after dark.

ColorVu technology is designed to improve colour imaging in low-light environments, while the camera can also use infrared illumination when appropriate. This makes the DS-2CD2T47G2H-LISU/SL a practical choice for surveillance where night-time detail matters.

Intelligent Human and Vehicle Detection
The camera uses deep learning-based human and vehicle classification to distinguish relevant targets from other movement. This can make security monitoring more efficient by helping focus alerts on people and vehicles.

Face capture is also supported, adding another useful function for surveillance applications where identifying or recording faces is important.

Active Deterrence and Two-Way Audio
The built-in speaker and microphone provide two-way audio communication. Security personnel can listen to activity around the camera and communicate with people in the monitored area.

When supported detection events occur, the active strobe light and audio alarm can be used as a deterrent. This gives the camera both monitoring and active security functions in one unit.

Network, Storage and Connectivity
The camera connects to the network through a 10M/100M self-adaptive RJ45 Ethernet port. On-board recording is supported through the built-in memory card slot, with compatibility for cards up to 512 GB.

Key connectivity and recording points include:

• 1 x RJ45 10M/100M self-adaptive Ethernet port
• Built-in memory card slot supporting up to 512 GB
• 1 x audio line input
• 1 x audio line output
• 1 x alarm input
• 1 x alarm output
• Built-in microphone
• Built-in speaker
• Up to 6 simultaneous live views

Video Compression and Bandwidth Management
The Hikvision network camera supports H.265, H.264, H.264+, and H.265+ video compression. H.265+ can help reduce bandwidth and storage requirements while maintaining suitable image quality, making it useful for installations where network capacity or recording storage needs to be managed.

The camera also supports one fixed region of interest, allowing an important area within the scene to receive greater attention during video encoding.

Outdoor Security Camera Design
Built for outdoor surveillance, the camera has an IP67-rated housing that provides protection against dust and water. This makes it suitable for a range of residential, commercial and industrial security installations when correctly mounted.

The fixed 2.8mm lens provides a wide viewing perspective that can be useful for monitoring entrances, walkways, yards, driveways and other areas where broad scene coverage is required.

Technical Details

• Model: DS-2CD2T47G2H-LISU/SL(2.8mm)(eF)(O-STD)
• Resolution: 4MP
• Maximum image resolution: 2688 x 1520
• Lens: 2.8mm fixed lens
• Supplemental light: IR and white light
• Supplemental light range: Up to 60m
• WDR: 130 dB
• Video compression: H.265, H.264, H.264+, H.265+
• Audio: Mono sound
• Network interface: 1 x RJ45 10M/100M self-adaptive Ethernet
• Storage: Built-in memory card slot up to 512 GB
• Audio input: 1
• Audio output: 1
• Alarm input: 1
• Alarm output: 1
• Intelligent detection: Human and vehicle classification
• Face capture: Supported
• Motion detection: Supported
• Region of interest: 1 fixed ROI
• Built-in microphone: Yes
• Built-in speaker: Yes
• Weather protection: IP67

Part Number and SKU
The part number / SKU for this Hikvision 4MP Smart Hybrid Light ColorVu bullet network camera is HK-311324227 . This reference can be used when checking stock, ordering the correct model or matching the camera with compatible Hikvision equipment.

Suitable Applications
The DS-2CD2T47G2H-LISU/SL is well suited to residential properties, offices, retail stores, warehouses, entrances, driveways, commercial premises and other locations requiring intelligent day and night surveillance. Its combination of 4MP imaging, ColorVu, Smart Hybrid Light, human and vehicle detection, active deterrence and two-way audio makes it a versatile network camera for modern security installations.

Specifications:

© 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	HK-311324227
Camera
Image Sensor	1/1.8" Progressive Scan CMOS
Max. Resolution	2688 x 1520
Min. Illumination	Color: 0.0005 Lux @ (F1.0, AGC ON),0 Lux with light
Shutter Time	1/3 s to 1 / 100,000 s
Day & Night	IR cut filter
Angle Adjustment	Pan: 0degrees to 360degrees,tilt: 0degrees to 90degrees,rotate: 0degrees to 360degrees
Lens
Lens Type	Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV	2.8 mm, horizontal FOV 104.0degrees, vertical FOV 54.4degrees, diagonal FOV 126.7degrees
	4 mm, horizontal FOV 89.2degrees, vertical FOV 45.5degrees, diagonal FOV 108.2degrees
Lens Mount	M16
Iris Type	Fixed
Aperture	F1.0
Depth of Field	2.8 mm: 2.5 m to ∞
	4 mm: 3.1 m to ∞
DORI
DORI	2.8 mm: D: 61 m, O: 24 m, R: 12 m, I: 6 m
	4 mm: D: 75 m, O: 30 m, R: 15 m, I: 7 m
Illuminator
Supplement Light Type	IR,White Light
Supplement Light Range	Up to 60 m
Smart Supplement Light	Yes
IR Wavelength	850 nm
Video
Main Stream	50 Hz: 25 fps (2688 x 1520, 1920 x 1080, 1280 x 720)
	60 Hz: 30 fps (2688 x 1520, 1920 x 1080, 1280 x 720)
Sub-Stream	50 Hz: 25 fps (1280 x 720, 640 x 480, 640 x 360)
	60 Hz: 30 fps (1280 x 720, 640 x 480, 640 x 360)
Third Stream	50 Hz: 10 fps (1920 x 1080, 1280 x 720, 640 x 480, 640 x 360)
	60 Hz: 10 fps (1920 x 1080, 1280 x 720, 640 x 480, 640 x 360)
	*The third stream is supported under certain settings.
Video Compression	Main stream: H.265/H.264/H.264+/H.265+
	Sub-stream: H.265/H.264/MJPEG
	Third stream: H.265/H.264
	*Third stream is supported under certain settings.
Video Bit Rate	32 Kbps to 8 Mbps
H.264 Type	Baseline Profile,Main Profile,High Profile
H.265 Type	Main Profile
Bit Rate Control	CBR,VBR
Scalable Video Coding (SVC)	H.264 and H.265 encoding
Region of Interest (ROI)	1 fixed region for main stream and sub-stream
Audio
Audio Type	Mono sound
Audio Compression	G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Audio Bit Rate	64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
Audio Sampling Rate	8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering	Yes
Network
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
Simultaneous Live View	Up to 6 channels
API	Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP
User/Host	Up to 32 users
	3 user levels: administrator, operator, and user
Security	Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Network Storage	NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR)
Client	iVMS-4200,Hik-Connect,Hik-Central
Web Browser	Plug-in required live view: IE 10, IE 11
	Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
	Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Image Parameters Switch	Yes
Image Settings	Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Day/Night Switch	Day,Night,Auto,Schedule
Image Enhancement	BLC,HLC,3D DNR,Defog
SNR	≥ 52 dB
Wide Dynamic Range (WDR)	130 dB
Privacy Mask	4 programmable polygon privacy masks
Interface
Ethernet Interface	1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage	Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Built-in Microphone	Yes,1 built-in microphone
Built-in Speaker	Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB.
Audio	1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
	1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Alarm	1 input, 1 output (max. 24 VDC/24 VAC, 1 A)
Reset Key	Yes
Event
Basic Event	Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage	Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,strobe light
Smart Event	Scene change detection
Deep Learning Function
Face Capture	Yes
Perimeter Protection	Line crossing, intrusion, region entrance, region exiting
	Support alarm triggering by specified target types (human and vehicle)
General
Power	12 VDC ± 25%, 0.88 A, max. 10.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection
	PoE: IEEE 802.3af, Class 3, max. 12.5 W
Material	Front cover: metal, body: metal, bracket: Metal
Dimension	286.7 mm x 93.3 mm x 91.2 mm (11.3" x 3.7" x 3.6")
Package Dimension	386 mm x 156 mm x 155 mm (15.2" x 6.1" x 6.1")
Weight	Approx. 1205 g (2.7 lb.)
With Package Weight	Approx. 1920 g (4.2 lb.)
Storage Conditions	-30 degreesC to 60 degreesC (-22 degreesF to 140 degreesF). Humidity 95% or less (non-condensing)
Startup and Operating Conditions	-30 degreesC to 60 degreesC (-22 degreesF to 140 degreesF). Humidity 95% or less (non-condensing)
General Function	Heartbeat,mirror,flash log,password reset via email,pixel counter,anti-banding
Language	33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
Approval
EMC	CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021
	RCM: AS/NZS CISPR 32: 2015
	IC: ICES-003: Issue 7
	KC: KN32: 2015, KN35: 2015
Safety	UL: UL 62368-1
	CB: IEC 62368-1: 2014+A11
	CE-LVD: EN 62368-1: 2014/A11: 2017
Environment	CE-RoHS: 2011/65/EU
Protection	IP67: IEC 60529-2013
