UB-UX7

Ubiquiti UniFi Express WiFi 7 Tri-band 10Gbps Cloud Gateway

Ubiquiti UniFi Express WiFi 7 Tri-band 10Gbps Cloud Gateway, UX7, 1x 10 GbE RJ45 WAN Port, 1x 2.5 GbE RJ45 LAN Port, 2.3 Gbps IDS/IPS Throughput, 5.7 Gbps @ 6GHz, 4.3 Gbps 5GHz, 688 Mbps @ 2.4GHz, USB Type-C Power Method, 0.96" status Display

Overview:

UniFi Express 7
UX7

Mesh-scalable, super-compact 10G Cloud Gateway with integrated WiFi 7.

Specifications:

© 2025 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	UB-UX7
Overview
Dimensions	117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67'')
UniFi Application Suite
Network	Yes
Managed UniFi Devices	30
Simultaneous Users Connected	300
Default WAN Ports	(1) 10 GbE RJ45
LAN Ports	(1) 2.5 GbE RJ45
IDS/IPS Throughput	2.3 Gbps
Form Factor	Compact desktop
Coverage Area	160 m² (1,750 ft²)
Security
Stateful Firewall	Yes
Application-Aware Layer 7 Firewall	Yes
DPI & Traffic Identification	Yes
Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)	Yes
Content Filtering	Yes
Intrusion Prevention (IPS/IDS)	Yes
Ad Blocking	Yes
IDS/IPS Signatures	20,000+ with CyberSecure
VLAN/Subnet-based Traffic Segmentation	Yes
VPN & SD-WAN
License-Free SD-WAN	Yes
Site-to-Site VPN
Site Magic	Yes
IPsec	Yes
OpenVPN	Yes
VPN Server
Identity Endpoint One-Click VPN	Yes
Teleport Zero-Configuration VPN	Yes
WireGuard	Yes
OpenVPN	Yes
L2TP	Yes
VPN Client
OpenVPN	Yes
WireGuard	Yes
Dynamic Routing
OSPF	Yes
Advanced QoS	Yes
Multicast DNS (mDNS)	Yes
Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)	Yes
Integrated RADIUS Server	Yes
RADIUS over TLS (RadSec)	Yes
Additional Internet Failover with UniFi LTE Backup	Yes
Internet Quality and Outage Reporting	Yes
Policy-based WAN and VPN Routing	Yes
Customizable DHCP Server	Yes
IPv6 ISP Support	Yes
IGMP Proxy	Yes
Integrated WiFi
WiFi Standard	802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
Throughput
6 GHz	5.7 Gbps
5 GHz	4.3 Gbps
2.4 GHz	688 Mbps
MIMO
6 GHz	2 x 2 (DL/UL MU-MIMO)
5 GHz	2 x 2 (DL/UL MU-MIMO)
2.4 GHz	2 x 2 (DL/UL MU-MIMO)
Antenna Gain
6 GHz	6 dBi
5 GHz	7 dBi
2.4 GHz	4 dBi
Wireless Security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
Max. BSSIDs	4 per Radio (Gateway Mode) 4 per Radio (AP Mode)
Supported Data Rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b	1, 2, 5.5, 11 Mbps
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n	6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5)	6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6/6E)	7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11be (WiFi 7)	7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Hardware
Max. Power Consumption	22W
Power Method	USB type C (5V DC/5A)
Power Supply	USB type C (5V DC/5A) (Adapter included)
Max. TX Power
6 GHz	24 dBm
5 GHz	26 dBm
2.4 GHz	23 dBm
Supported Voltage Range	100-240V AC
Processor	Quad-core ARM Cortex -A53 at 1.5 GHz
System Memory	3 GB
Weight	422 g (14.9 oz)
Enclosure Material	Polycarbonate
LCM Display	0.96" status display
Management	Ethernet Bluetooth
LEDs
Ethernet	Yes
ESD/EMP Protection	Air: ± 8kV, contact: ± 4kV
Ambient Operating Temperature	-10 to 40° C (14 to 104° F)
Ambient Operating Humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
Button	(1) Factory-reset
Software
VLAN	802.1Q
Guest Traffic Isolation	Yes
Application Requirements
UniFi Network	Version 9.0.108 and later
