DS-3E1518P-SI-16P2F

Hikvision L2 Smart Managed 16 port Gigabit Smart PoE Switch with 2x Gigabit SFP Ports

Hikvision L2 Smart Managed 16 port Gigabit Smart PoE Switch with 2x Gigabit SFP Ports, Metal material Shell, 16 x Gigabit PoE Port, 2 x Gigabit SFP Fiber Optical Port, Ports 1 to 16 up to 300m, 30 W Maximum Port Power, 230 W PoE Power budget

Overview:

The Hikvision DS-3E1518P-SI-16P2F is a 16 port Gigabit Smart PoE switch designed for reliable network connectivity and efficient power delivery to compatible devices. With 16 Gigabit PoE ports and 2 Gigabit SFP fiber ports, it provides a flexible networking solution for IP cameras, wireless access points, VoIP phones and other PoE-enabled equipment. The 230 W PoE power budget allows multiple connected devices to receive power directly through the network cables, helping simplify installations.

Description:

The Hikvision DS-3E1518P-SI-16P2F combines Gigabit Ethernet connectivity with smart network management and PoE support. Its metal housing provides a durable design for network installations, while the two SFP ports allow for Gigabit fiber uplinks where longer-distance or fiber-based connectivity is required.

Ports 1 to 16 support extended transmission distances of up to 300 metres when used with compatible equipment and suitable cabling. Each PoE port can deliver up to 30 W, with a total available PoE power budget of 230 W. This makes the switch well suited to surveillance networks and other installations where several powered network devices need to operate from a central switch.

The switch also includes network management functions such as VLAN tagging, loop prevention and storm control. Cable detection can assist with locating cable faults, while 6 kV surge protection helps provide additional protection for connected network equipment.

Features:

Gigabit PoE Networking for IP Devices
With 16 x 10/100/1000M PoE ports, the switch can connect and power a range of compatible devices without requiring separate power supplies at each endpoint. Gigabit speeds provide suitable bandwidth for demanding network applications, including IP surveillance systems.

The two 100/1000M SFP ports provide options for Gigabit fiber optical connections, making the DS-3E1518P-SI-16P2F suitable for installations where a fiber uplink is preferred.

Key technical points include:

• 16 x 10/100/1000M Gigabit PoE ports
• 2 x 100/1000M SFP fiber optical ports
• 230 W total PoE power budget
• Up to 30 W PoE power per port
• Ports 1 to 16 support transmission distances of up to 300 m
• Metal material shell
• IEEE 802.1Q VLAN tagging support
• STP, RSTP and ERPS loop prevention
• Storm control support
• Cable detection for locating connection failures
• 6 kV surge protection
• User-configurable energy saving plans

Smart Network Management
The switch provides useful Layer 2 smart management capabilities for businesses, surveillance installations and structured network environments. IEEE 802.1Q VLAN support allows network traffic to be logically separated, while STP, RSTP and ERPS help reduce the risk of network loops affecting connectivity.

Storm control provides an additional method of managing excessive network traffic, helping maintain stable network performance when connected devices generate unexpected traffic levels.

Energy Saving and Installation Support
An energy saving mode with user-configurable plans can help manage power usage according to the requirements of the installation. Cable detection is also included, giving installers and network administrators a practical way to identify potential cable faults.

For surveillance and security applications, the extended PoE transmission capability can help simplify installations where cameras or other network devices need to be positioned further from the switch.

Hikvision DS-3E1518P-SI-16P2F for Network and Surveillance Systems
The DS-3E1518P-SI-16P2F is a practical choice for CCTV networks, offices, access control systems, wireless networking and other installations requiring multiple Gigabit PoE connections. Its combination of 16 PoE ports, a 230 W power budget and dual Gigabit SFP uplinks provides flexibility for expanding a network while reducing the need for separate power infrastructure.

For ordering and product identification, the part number / SKU is DS-3E1518P-SI-16P2F.

Specifications:

© 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	DS-3E1518P-SI-16P2F
General
Shell	Metal material
Net Weight	2.56 kg (5.64 lb)
Gross Weight	3.479 kg (7.67 lb)
Dimensions (W x H x D)	440.0 mm x 44.0 mm x 220.8 mm (17.32'' x 1.73'' x 8.69'')
Operating Temperature	0 degreesC to 45 degreesC (0 degreesF to 113 degreesF)
Storage Temperature	-40 degreesC to 85 degreesC (-40 degreesF to 185 degreesF)
Operating Humidity	5% to 95% (no condensation)
Relative Humidity	5% to 95% (no condensation)
Power Supply	100 to 240 V AC, 50/60 Hz, Max. 4 A
Installation Mode	Rack (equipped with mounting ears)
Max. Power Consumption	250 W
Power Consumption in Idle	10 W
Surge Protection	6 kV
Network Parameters
Ports	16 x Gigabit PoE port,2 x Gigabit fiber optical port
MAC Address Table	8 K
Switching Capacity	56 Gbps
Packet Forwarding Rate	41.66 Mpps
Internal Cache	4.1 Mbits
Software Function
Long Range	Ports 1 to 16: up to 300 m.
	Long range performance may vary depend on camera model or cable condition.
Port Isolation	Ports 1 to 18: port isolation mode to improve network security
	Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.
PoE Watchdog	Ports 1 to 16: auto detect and restart the cameras that do not respond.
Link Aggregation	Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection.
	Support static link aggregation.
	Support 8 aggregation groups.
QoS	QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance.
	Support port-based priority configuration.
	Support SP, WRR priority schedule mode.
Loop Prevention	Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default.
	Support 802.1D STP.
	Support 802.1w RSTP.
	Support G.8032 ERPS.
VLAN	VLAN is used for network scale planning and network health improvement.
	Support 802.1Q.
	Configurable VLAN ID from 1-4094.
	Support Trunk, Access port mode.
	Support Max. 4094 VLAN.
HPP	Support one-click activation and remote management via Hik-Partner Pro. Functions supported:
	1. Display the port rate.
	2. Display the port bandwidth utilization rate.
	3. Display the PoE power usage.
	4. Display topology information.
	5. Display the alarm status.
	6. Restart ports and devices.
	7. Enable port long-rage mode.
	8. Remotely upgrade the device.
System Maintenance	Support device management via web.
	Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses.
	Support Super IP, which is a fixed IP address (10.180.190.200) for direct access.
	Support management via Hik-Central Pro.
	Support remote management via Hik-Partner Pro.
	Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected.
	Support 802.1ab LLDP for peer device discovery.
	Support SNMP v1/v2c for third-party management platform access.
	Support port mirroring for fault locating.
Port Rate-Limiting	Port rate-limiting is used for port bandwidth adjustment to prevent network congestion.
Storm Control	Storm control is used to prevent switch ports from being blocked by broadcast or multicast storms in the LAN, which may affect network communication.
	Support port rate limiting based on broadcast, multicast, and unknown unicast packets.
DHCP Snooping	DHCP Snooping can prevent unauthorized connections to DHCP servers from disrupting the network and affecting normal network communication, and only allow DHCP packets from trusted ports to pass through. Disabled by default.
ACL	Support ACL definitions based on source/destination MAC address, source/destination IP address, IP protocol type.
	Support ACL application on ports.
	Support IPv4 ACL and MAC ACL configurations.
	Support inbound ACLs.
IPSG	IPSG can control the security of port access device.
	Support port, MAC, IP binding.
	Support 256 security entries.
PoE Power Supply
PoE Standard	IEEE 802.3af,IEEE 802.3at
PoE Power Pin	8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
PoE Port	PoE: Ports 1 to 16
Max. Port Power	30 W
PoE Power Budget	230 W
Approval
EMC	CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
Safety	CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017)
Chemistry	CE-RoHS (201165EU)
	WEEE (201219EU)
	Reach (Regulation (EC) No.19072006)
