CD-M30003

Cudy M3000 Dual Band WiFi 6 3000 Mbps Multi-Gigabit Mesh - 3 pack

Cudy M3000 Dual Band WiFi 6 3000 Mbps Multi-Gigabit Mesh - 3 pack, 2402 Mbps @ 5GHz Wi-Fi Speed, 574 Mbps 2 2.4GHz Wi-Fi Speed, 5x internal Wi-Fi antennas, 5.1dBi 5GHz antenna gain Max, 4.2dBi 2.4GHz antenna gain Max, Beamforming, 1x 2.5G RJ45 WAN Ports, 1x Gigabit RJ45 LAN Ports, Operation modes - Wi-Fi Router / Access Point / Range Extender / WISP / Client

Overview:

AX3000 2.5G Wi-Fi 6 Mesh System - Cudy M3000 3 Pack
A mesh WiFi 6 system with five antennas to provide a super-fast network for large homes with 4K streaming and gaming demands. Suitable for internet access up to 2.5 Gbps.

Description:

The Cudy M3000 is a dual-band Wi-Fi 6 mesh system designed to deliver fast, reliable wireless coverage across larger homes. With combined wireless speeds of up to 3000 Mbps, a 2.5G Ethernet WAN port and support for multi-band simultaneous backhaul, the three-unit system is well suited to 4K streaming, online gaming, home working and networks with many connected devices.

Its 1.3 GHz dual-core processor, 4-stream Wi-Fi 6 technology, OFDMA and MU-MIMO help maintain responsive connections when multiple users and smart devices are online at the same time. Fast roaming allows devices to move between mesh nodes with less interruption, while beamforming helps direct wireless performance towards connected devices.

Features:

Cudy M3000 Wi-Fi 6 Mesh Performance
The M3000 provides up to 2402 Mbps on the 5 GHz band and up to 574 Mbps on the 2.4 GHz band. The 160 MHz channel bandwidth is designed to provide higher throughput and responsive performance for demanding applications such as 4K video streaming and FPS gaming.

Key wireless capabilities include:

• AX3000 dual-band Wi-Fi 6
• Up to 2402 Mbps at 5 GHz
• Up to 574 Mbps at 2.4 GHz
• 4-stream wireless architecture
• 160 MHz channel bandwidth
• OFDMA and MU-MIMO
• Beamforming
• Fast roaming
• Support for up to 200 connected devices
• Multi-band simultaneous backhaul

Reliable Coverage for Busy Homes
The three-unit Cudy M3000 mesh system is designed to provide consistent Wi-Fi coverage throughout larger homes. Five internal Wi-Fi antennas per unit help provide strong wireless performance, with antenna gain of up to 5.1 dBi on 5 GHz and 4.2 dBi on 2.4 GHz.

With Cudy Mesh technology, the system can distribute wireless coverage between nodes while fast roaming helps compatible devices transition between access points as you move around the home.

2.5G Multi-Gigabit Connectivity
A 2.5G RJ45 WAN port provides support for internet connections of up to 2.5 Gbps, making the M3000 suitable for high-speed fibre and other multi-gigabit broadband services. Each unit also includes a Gigabit RJ45 LAN port for wired devices.

The system can operate in several networking modes, allowing it to be adapted to different home and small-office setups:

• Wi-Fi Router
• Access Point
• Range Extender
• WISP
• Client

Gaming and 4K Streaming
The combination of Wi-Fi 6, 160 MHz bandwidth, OFDMA, MU-MIMO and a dual-core processor helps reduce congestion and latency when the network is under load. This makes the M3000 suitable for online gaming, 4K streaming, video calls and other bandwidth-intensive activities.

Multiple devices can remain connected without requiring the network to be limited to only one high-bandwidth user. The system supports up to 200 connected devices, making it practical for households with smartphones, laptops, smart TVs, consoles, cameras and IoT equipment.

Parental Controls and Network Security
The M3000 includes tools for managing internet access and controlling how connected devices use the network. Parents can set online time limits for selected devices and restrict access to inappropriate web domains.

WPA3 wireless security provides stronger protection against brute-force attacks, while a separate guest network can isolate visitors from your main network and connected devices.

VPN Server and Client Support
Built-in VPN server and client functionality adds flexibility for users who require secure remote access or want to connect the network through a VPN service. The M3000 supports six VPN protocols and is compatible with more than 50 commercial VPN providers.

Cudy App and Cloud Management
Network management can be handled from a smartphone using the Cudy App. The system supports both local management and cloud-based remote control, making it easier to monitor and manage the network without needing to access the router through a computer.

A built-in system panel provides information about network status, while diagnostic tools can assist with identifying connection problems and troubleshooting common issues.

Cudy M3000 Technical Details

• Product: Cudy M3000 Dual Band Wi-Fi 6 Mesh System
• Pack: 3 units
• Wireless standard: Wi-Fi 6
• Wireless class: AX3000
• 5 GHz speed: Up to 2402 Mbps
• 2.4 GHz speed: Up to 574 Mbps
• CPU: 1.3 GHz dual-core
• Wi-Fi antennas: 5 internal antennas
• Maximum 5 GHz antenna gain: 5.1 dBi
• Maximum 2.4 GHz antenna gain: 4.2 dBi
• WAN port: 1 x 2.5G RJ45
• LAN port: 1 x Gigabit RJ45
• Connected devices: Up to 200
• Security: WPA3
• Mesh technology: Cudy Mesh
• VPN: Server and client support
• Management: Cudy App, local control and cloud control
• Beamforming: Supported
• Fast roaming: Supported

Part Number / SKU
The part number / SKU for this Cudy M3000 three-pack Wi-Fi 6 Mesh System is CD-M30003, making it easy to identify the correct product when ordering or checking stock.

Who Is the Cudy M3000 For
The Cudy M3000 is a practical choice for larger homes that need dependable Wi-Fi coverage, high wireless throughput and support for numerous connected devices. It is particularly suited to households using high-speed fibre internet, 4K streaming services, gaming consoles, smart home equipment and multiple mobile devices.

With its 2.5G WAN connection, AX3000 Wi-Fi 6 performance, mesh roaming and flexible operating modes, the M3000 provides a scalable wireless networking solution for demanding home networks.

Specifications:

© 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	CD-M30003
Model Version
Model Version	M3000 1.0
CPU
Chipset	MT7981
CPU Details	1.3 GHz Dual-Core, ARM Cortex-A53
Memory/Storage
Flash/ROM	128 MB (1 Gbit) NAND
DDR/RAM	256 MB (2 Gbit) DDR3
Wireless
5 GHz Wi-Fi Speed	2402 Mbps
2.4 GHz Wi-Fi Speed	574 Mbps
5 GHz Wi-Fi Streams	2T2R (2x2 MIMO)
2.4 GHz Wi-Fi Streams	2T2R (2x2 MIMO)
Wi-Fi Antennas	5x Internal
5 GHz Antenna Gain Max	5.1dBi
2.4 GHz Antenna Gain Max	4.2dBi
FEM or PA/LNA	5 GHz: 3x Internal
	2.4 GHz: 2x Internal
Beamforming	True
Range Performance	Max: 200 m (656 ft)
	Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance	Two wooden walls with thickness < 10 cm (4'')
	One concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4'')
Multi-Pack Indoor Coverage	2 Pack: 400 m² (3900 sq ft)
	3 Pack: 600 m² (5500 sq ft)
	Applied to wireless backhaul situation. Place in the center of each floor, with a maximum of three obstacles to each room.
Interfaces
2.5G RJ45 Ports	1
Gigabit RJ45 Ports	1
Ethernet Notes	The 2.5G port is WAN port, the Gigabit port is LAN port
LED	System
	Speed/Link/ACT of Ethernet Port
Physical Buttons	WPS Button
	Reset Button
Power Input	DC Jack
Power
Power Methods	DC
DC	12V 1A
Power Adapter	Input: 100 ~ 240 V, 50/60 Hz AC
	Output: 12V 1A DC
Reliability
Environment	Operating Temperature: 0 degreesC ~ 40 degreesC (32 degreesF ~104 degreesF)
	Storage Temperature: -40 degreesC ~ 70 degreesC (-40 degreesF ~ 158 degreesF)
	Humidity: 10% ~ 90% non-condensing
	Storage Humidity: 5% ~ 95% non-condensing
Certifications
Certifications	FCC, CE
Mechanical
Installation	Desktop
Dimension	Ø110x154.5 mm
	Ø4.33x6.08 inches
Product Weight	360 g (12.7 oz.)
Package Content
Package Content	M3000
	Power Adapter
	Ethernet Cable
	Installation Guide
Ordering Information
Retail Package Weight	1-Pack , EU / US: 680 g (23.99 oz.)
	3-Pack , EU / US: 1500 g (52.91 oz.)
	2-Pack , EU / US: 1100 g (38.8 oz.)
	3-Pack , EU / US: 1827 g (64.45 oz.)
Retail Package Dimension	1-Pack:
	145x130x265 mm
	5.71x5.12x10.43 inches
	2-Pack:
	330x130x265 mm
	12.99x5.12x10.43 inches
	3-Pack:
	380x130x265 mm
	14.96x5.12x10.43 inches
Units per Carton	1-Pack: 16
	2-Pack: 8
	3-Pack: 4
Carton Dimension	1-Pack: 57x56x26 cm
	22.44x22.05x10.24 inches
	2-Pack: 55x54.5x35.3 cm
	21.65x21.46x13.9 inches
	3-Pack: 53.6x40x28.7 cm
	21.1x15.75x11.3 inches
Carton Gross Weight	1-Pack , EU / US: 12.2 kg (26.9 lbs)
	3-Pack , EU / US: 9.6 kg (21.16 lbs)
	2-Pack , EU / US: 12 kg (26.46 lbs)
	3-Pack , EU / US: 8.2 kg (18.08 lbs)
Carton Net Weight	1-Pack , EU / US: 10.9 kg (24.03 lbs)
	3-Pack , EU / US: 8.5 kg (18.74 lbs)
	2-Pack , EU / US: 11.5 kg (25.35 lbs)
	3-Pack , EU / US: 7.3 kg (16.09 lbs)
Model Version
Model Version	M3000 1.0
Wireless
Wi-Fi Standards	Wi-Fi 6
Max Wi-Fi Modulation	1024-QAM
Wi-Fi Efficiency	OFDMA
	MU-MIMO
	BSS Color
Max Capacity	512
Recommended Client Upper Limit	200
Max Wi-Fi Channel Width	160 MHz
Wi-Fi Security	WPA/WPA2/WPA3
Guest Network	2.4 GHz, 5 GHz
WPS	True
General
Operation Modes	Wi-Fi Router
	Access Point
	Range Extender
	WISP
	Client
Mesh	Cudy Mesh
Mesh Backhaul	Wireless Backhaul
	Wired Backhaul
Multi-Band Backhaul	True
WAN Mode	DHCP
	Static IP
	PPPOE
Internet Failover Sequence	WAN
	WISP
Network
QoS	Per-User Rate Limiting
DHCP	Address Reservation
	DHCP Client List
	Server
IP Versions	IPv4/IPv6
IPv6 Protocols	Relay
	Dynamic (SLAAC/DHCPv6)
	Staic (Fixed IP)
	Passthrough
	464XLAT
	MAP-E
	DS-Lite
IPTV/VLAN	Bridge
	Tag VLAN
TTL Customization	Extend
	Spoof
	Custom
IGMP	IGMP Proxy
	IGMP Snooping
Forwarding	Port Forwarding
	Port Triggering
	UPnP
	DMZ
Firewall	SPI Firewall
	DoS Protection
	Block PING
Application Layer Gateway	IPSec Passthrough
	L2TP Passthrough
	PPTP Passthrough
	FTP Passthrough
	TFTP Passthrough
	H323 Passthrough
	SIP Passthrough
	RTSP Passthrough
Utilities
VPN Server	WireGuard
	OpenVPN
	IPsec
	Zerotier
	PPTP
	L2TP
VPN Client	WireGuard
	OpenVPN
	IPsec
	Zerotier
	PPTP
	L2TP
DNS Options	DNS over TLS
	Manual DNS
	Rebind Protection
