Hikvision DS-K1T502DBFWX-C Access Control Terminal
The Hikvision DS-K1T502DBFWX-C is an advanced access control terminal designed to combine secure door access, fingerprint recognition, card authentication and video intercom functions in a single device. With support for fingerprint, card and PIN authentication, it provides flexible access management for offices, commercial buildings, residential properties and other controlled entry environments.
Built with a durable zinc alloy construction and IP65 and IK09 protection, the terminal is designed for reliable operation in demanding environments. Its integrated 2MP camera, network connectivity and Hik-Connect support also allow users to manage access and communication functions remotely.
The DS-K1T502DBFWX-C provides a versatile access control solution with a high-capacity fingerprint reader, card support and PIN authentication. It can store up to 10,000 fingerprints and 100,000 cards, making it suitable for installations with a large number of authorised users. The built-in 2MP camera supports video intercom functionality, while H.264 and H.265 compression helps manage video data efficiently.
The terminal supports SIP-based video intercom and can communicate with compatible SIP servers and indoor stations. It also supports Wiegand communication for connection to an external access controller, while RS-485 provides additional connectivity for external card readers and elevator calling applications.
Remote management is supported through the Hik-Connect mobile app, providing convenient access control management when connected to a suitable network. The device also supports AP mode, wired and wireless network priority settings and local or platform-based PIN configuration.
Secure Access Control
Multiple authentication options allow the DS-K1T502DBFWX-C to be configured for different security requirements. Users can authenticate using fingerprints, M1 cards, DESFire cards or PIN codes, providing flexibility for different access scenarios.
Video Intercom and Communication
The integrated 2MP camera supports video intercom applications, allowing the terminal to provide both access control and communication functions. SIP protocol support enables integration with compatible systems and selected SIP servers.
The calling button can be configured to contact a management centre, indoor station, specified indoor station or the Hik-Connect App. Supported SIP server platforms include Brekeke, miniSipServer, FreePBX, Asterisk, 3CX, ELASTIX and PBX ware.
Network and System Connectivity
A 10/100 Mbps self-adaptive wired network connection provides reliable communication with the access control system. The terminal also supports wireless connectivity and allows the priority between wired and wireless networks to be configured.
Connectivity options include:
Durable Design for Access Control Installations
The zinc alloy construction provides increased stability and durability, while IP65 protection helps protect the terminal against dust and water exposure. IK09 impact protection adds further resistance for installations where the device may be exposed to physical impact.
The Linux operating system provides the platform for the terminal's access control, communication and management functions.
Key Technical Details
Flexible Access Management
The combination of biometric authentication, card access, PIN support, video intercom and remote management makes the Hikvision DS-K1T502DBFWX-C a practical choice for modern access control installations. Its range of communication interfaces also allows it to integrate with additional access control hardware, card readers and elevator systems as required.
| © 2026 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered. | |
Specifications | |
| Product Code | HK-302918809 |
| System | |
| Operating system | Linux |
| Video | |
| Lens | 1 |
| Video compression standard | H.264 and H.265 |
| Resolution | 2 MP |
| FOV | HFOV = 110degrees , VFOV = 81degrees , DFOV = 122degrees |
| Video standard | PAL (Default) and NTSC |
| Network | |
| Wired network | 10 M/100 M self-adaptive |
| Wi-Fi | Support |
| Interface | |
| Network interface | 1 |
| Lock control | 1 |
| Exit button | 1 |
| Door contact input | 1 |
| Alarm input | 1 |
| Alarm output | 1 |
| TAMPER | 1 |
| RS-485 | 1 |
| Wiegand | 1 (output) |
| SD Card Slot | 1 |
| Capacity | |
| Fingerprint capacity | 10000 |
| Card capacity | 100000 |
| Event capacity | 300000 |
| Authentication | |
| Fingerprint module | Capacitive fingerprint recognition |
| Card type | M1 card , DESfire card |
| Card reading distance | 0 ~ 3 cm |
| General | |
| Power supply | 1 A (12 VDC to 24 VDC) |
| Power consumption | ≤12 W |
| Working temperature | -40 degreesC to +70 degreesC (-40 degreesF to +158 degreesF) |
| Protective level | IK09, IP65 |
| Language | Arabic, English, French, Indonesian, Italian, Portuguese (Brazil), Russian, Spanish (Europe), Thai, Ukrainian, Vietnamese, German, Polish, Hungarian, Czech, Romanian, Bulgarian, Croatian, Serbian, Greek, Slovak, Portuguese, Dutch, and Turkish |
| Function | |
| Two-way audio | Support |
| Video intercom | Support |
| Hik-Connect | Support |
