Specifications:
| © 2022 Respective owners and brand holders. This table has been carefully researched and generated by Laptop Direct CC (https://www.laptopdirect.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered. | |
| Specifications | |
| Product Code | ME-10000-WPTVa |
| item | ME-6000-WPTV / ME-10000-WPTV |
| Dimensions W*D*H(mm) | 248 x 500 x616 248 x500 x616 |
| Weight(kg) | 58.9 62.1 |
| Power | |
| Apparent Power(KVA) | 6KVA / 10KVA |
| Active power(KW) | 5.4KW / 9KW |
| Mains | |
| Voltage range | 120Vac-275Vac(phase to phase) |
| Current | 32.1A max 52.6 A max |
| Frequency range | 40Hz-70Hz |
| Power factor | 0.99 |
| Output | |
| Rating Voltage | 230Vac(±1%) |
| Rating Current | 27A 45A |
| Frequency range | 50Hz x (1±1%), Follow main power in phase lock range |
| Power factor | 0.9 |
| 105%-125%, load transfer to bypass mode after 10 min (0-30°C) or | |
| 1min(30-40°C) | |
| Output Overload | 125%-150%, load transfer to bypass mode after 30s |
| Over 150%, load transfer to bypass after 0.5s | |
| Load crest ratio | 3:1( max) |
| THD | <2%( 100% Line load) |
| Enviromental and safety | |
| EMC Standard | EN IEC 62040-2:2018 / EN 62040-2:2006 / IEC 62040-2:2016 |
| Safety Standard | EN62040-1:2008+A1:2013 |
| Operation | |
| Operation | 0-40 °C |
| temperature | |
| Store temperature | -25 °C to 55 °C |
| Relative humidity | 20% to 90% |
| Altitude | <1000m |
